High Accuracy Submersible Level Transmitter Reinforcement Cables Optional

Name: High Accuracy Submersible Level Transmitter Reinforcement Cables Optional
Brand: Atech
Price: 1 USD

High Accuracy Submersible Level Transmitter Reinforcement Cables Optional Manufactures

Brand Name : Atech

Model Number : PL312

Certification : CE

Place of Origin : China

MOQ : 1pc

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 pcs month

Delivery Time : 5-8 work days

Packaging Details : standard export packing ,carton packing, water proof, shock resistance or according to customer's requirements.

pressure medium : liquid compatible stainless steel

Pressure ranges : 0~1 m H2O...100 m H2O

overload pressure : 200%FS

output signal : 4~20mA

accuracy : 0.5%FS (standard)

load resistance : RL = (U-10)/0.02(Ω) (4~20mA current output), ＞20KΩ (voltage output)

long term stability : 0.25%FS/year

Power supply : 10-36VDC

Contact Now

Submersible pressure transducer PL312 ceramic capacitor submersible level transmitter

Feature

● High accuracy

● Long service life

● E+H ceramic capacitor sensor cell

● CE certificate

● Reinforcement cables optional

Applications

● Industrial wastewater measurements
● Strong acid ,strong alkali liquid measurements

● Liquid measuring for petroleum ,metallurgy
● Sea water level measurements and control

● vitriol measurements

● Tank level monitoring

● Circulation fluid monitoring

Description

PL312 series are full sealed submersible level transmitter. It is employed high stable and reliable E+H ceramic capacitor pressure sensor and high accurate circuit board into the stainless steel housing. Integrated construction and standard signal provide the user easy and convenient application in the local working place.
PL 312 ceramic capacitor level transmitter has compact size, light weight and good stability; it can be used for waste water or liquid measure and control of oil and fuel tank level, medicine, metallurgy, electricity, mine, city water supply and drainage and hydrology, etc.

Speifications

pressure medium	liquid compatible stainless steel
pressure ranges	0~1 m H2O...100 m H2O
overload pressure	200%FS
output signal	4~20mA
accuracy	0.5%FS (standard) 0.25%FS
load resistance	RL = (U-10)/0.02(Ω) (4~20mA current output), ＞20KΩ (voltage output)
long term stability	0.25%FS/year
supply voltage	10-36VDC
compensated temperature range	-20°c ~70°c
operating temperature range	-20°c ~70°c
storage temperature range	-40~+125°c
temperature coefficient of zero	1%FS (Max)
temperature coefficient of span	1%FS (Max)
insulation resistance	100MΩ@ 50VDC
Pressure connection	screw thread, throw-in type
Protection grade	IP68
material of wetted part and housing	1Cr18Ni9Ti
material of pressure membrane	Ceramic
Response time	10ms

High Accuracy Submersible Level Transmitter Reinforcement Cables Optional
