0.5 ~4.5V RS485 Submersible Water Level Sensor Hydraulic Monitoring

Name: 05 45V RS485 Submersible Water Level Sensor Hydraulic Monitoring
Brand: Atech
Price: 1 USD

Brand Name : Atech

Model Number : PL301

Certification : CE, RoHs ,ISO 9001

Place of Origin : China

MOQ : 1pc

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 pcs month

Delivery Time : 5-8 work days

Packaging Details : standard export packing ,carton packing, water proof, shock resistance or according to customer's requirements.

pressure medium : water and other liquid

Pressure ranges : 0~0.5 m H2O...500 m H2O

overload pressure : 150%FS

output signal : 4~20mA, 0.5 ~4.5V, 0~5V,RS485, RS232, 868 Mhz 4~20mA+Hart

accuracy : 0.1%FS、0.25%FS、0.5%FS (standard)

pressure sensor : silicon pressure sensor

Power supply : 24VDC ,12VDC，10-30VDC

operating temperature range : 0~+85°c

Contact Now

0.5 ~4.5V RS485 Submersible Water Level Sensor Hydraulic Monitoring

Feature of Submersible Water Level Sensor

Excellent impact resistance, overload resistance,vibration resistance and corrosion resistanceMoisture proof, anti-condensation, anti-leakage,protection class lP68
Efficient lightning protection,strong anti-radiation andelectromagnetic interference protection

Specifications of Submersible Water Level Sensor

ssure medium	liquid compatible stainless steel
pressure ranges	0~1 m H2O...300 m H2O
overload pressure	150%FS
output signal	4~20mA, 0.4 ~4.5V, 0~5V, RS485, RS232, 868 Mhz 4~20mA+Hart
accuracy	0.1%FS,0.25%FS,0.5%FS (standard)
load resistance	RL = (U-10)/0.02(Ω) (4~20mA current output), ＞20KΩ (voltage output)
long term stability	0.2%FS/year
supply voltage	10~36VDC
compensated temperature range	-10~70°c
operating temperature range	-20~85°c
storage temperature range	-40~125°c
temperature coefficient of zero	±0.015%FS/°c@25°c
temperature coefficient of span	±0.02%FS/°c@25°c
insulation resistance	100MΩ@ 250VDC 100MΩ@ 500VDC
Pressure connection	screw thread, throw-in type
Protection grade	IP68
material of wetted part and housing	304SS or 316L
material of pressure membrane	316L
Response time	1ms

Applications PL301 Submersible level sensor

● Hydraulic monitoring
● Frequency water supply

● Liquid measuring for petroleum ,metallurgy
● City water supply

● Sewage treatment

● Tank level monitoringT

● Water-saving irrigation

● Circulation fluid monitoring
